Category | Parameter | Details / Value |
Physical Specifications | Dimensions | 178 × 83 × 17 mm |
| Weight | Approx. 580g |
| Color | Black (Black rear shell, Black front shell) |
| Screen Size | 5.0-inch (Optional 5.72-inch Full Screen) |
| Screen Resolution | 1280 × 720 / Full Screen: 1440 × 720 |
| Touch Screen | Multi-touch, Corning Gorilla Glass 3 tempered screen |
| Front Camera | 5.0 MP |
| Rear Camera | 13.0 MP, Auto Focus with Flash |
| Speaker | Built-in 8Ω/0.8W waterproof speaker × 1 |
| Microphone | Built-in, Sensitivity: -42dB, Output Impedance: 2.2kΩ |
| Battery | Non-removable dual polymer lithium battery |
| Battery Capacity | 3.7V / 10000mAh |
| Battery Life | Approx. 16 hours (Standby time > 600 hours) |
Performance Parameters | Processor (CPU) | MTK 6762, Octa-core |
| CPU Speed | 2.0 GHz |
| RAM + ROM | 3GB + 32GB (Optional 4GB + 64GB) |
| Operating System | Android 12.0 |
| NFC | Built-in support for ISO/IEC 14443A protocol, Read range: 1-3cm |
Data Communication | Wi-Fi Standard | Wi-Fi 802.11 b/g/n/a/ac |
| Wi-Fi Frequency | 2.4GHz + 5GHz Dual-band |
| Bluetooth | BT4.0 (BLE) |
| Cellular (4G LTE) | LTE FDD: B1, B3, B5, B7, B8, B20
LTE TDD: B38, B39, B40, B41
WCDMA: 1/2/5/8
GSM: 2/3/5/8 |
| Positioning | Beidou / GPS / Glonass |
Data Capture | Fingerprint Module | Capacitive USB press-type module |
| Fingerprint Image Size | 256 × 360 pixels |
| Certification | FBI PIV FAP 10 certified (USA), MPS (China), STQC (India) |
| Image Resolution | 508 DPI |
| Int'l Standards | Compliant with ISO 19794-2, ISO 19794-4, ANSI 378, ANSI 381 & WSQ |
| Capture Speed | Single-frame image capture time ≤ 0.25s |
| 1D Barcode Scanner | Zebra SE965 |
| 1D Optical Resolution | 5 mil |
| 1D Scan Speed | 50 scans/sec |
| Supported 1D Codes | UPC/EAN, Bookland EAN, UCC Coupon Code, ISSN EAN, Code 128, GS1-128, ISBT 128, Code 39, Trioptic Code 39, Code 32, Code 93, Code 11, Honeywell HS78, Zebra SE4710 |
| 2D Barcode Scanner | NLS-CM60 & NLS-N1 |
| 2D Optical Resolution | 5 mil |
| 2D Scan Speed | 50 scans/sec |
| Supported 2D Codes | PDF417, MicroPDF417, Data Matrix, Data Matrix Inverse, Maxicode, QR Code, MicroQR, QR Inverse, Aztec, Aztec Inverse, Han Xin, Han Xin Inverse |
| LF RFID | Supports 125KHz and 134.2KHz; Effective read range: 3-5cm |
| HF RFID | 13.56MHz, Supports 14443 A/B, 15693 protocols; Effective read range: 3-5cm |
| UHF RFID | China Frequency: 920-925MHz
USA Frequency: 902-928MHz
Europe Frequency: 865-868MHz
Protocol: EPC C1 GEN2/ISO 18000-6C
Antenna: Ceramic antenna (4dBi)
Read Range: 1-25m (depending on tag) |
| ID Card Reader | Supports online decryption of Chinese Second-Generation Resident ID cards |
| Facial Recognition | Embedded facial recognition algorithm |
| Infrared Thermometry | 1-3cm non-contact; Accuracy: ±0.2°C; Range: 32°C to 42.9°C (Body Mode); Measurement time: ≤1s |
Reliability | Drop Specification | 1.5 meters (operating state) |
| Tumble Test | 1000 tumbles (6 sides) |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 5% RH to 95% RH (non-condensing) |
