UL008

UHF NXP/ U CODE 9XE Jewelry Tag

- Operation Frequency:  860-960MHZ

Size: 104*27.5mm




Collect
  • Description

1. Electrical Characteristics

Item

 Description

Remarks

chip

NXP/U Code 9XE



N/A



Base material

PET



N/A



Antenna fabrication process



Al (9 μm) +PET (50 μm)

Etched Aluminum (9 μm)

+ PET (50 μm)

CN0292



Standards compliant



EPC Class1 Gen2



N/A





 IC Memory

EPC

128bits







N/A

User

0

TID

96bits

Access

Password

0



frequency

860-960MHZ



N/A



IC Life



100,000 Programming cycles,

10years data retention



N/A



Read  Range

6-9M



N/A



ESD Voltage

±2kV

HBM

(Human Body Model)


- Temperature/Humidity for Label Attach (T/H): [18℃ to 40℃] 20% to 80%RH

- Temperature/Humidity after Label Attached to the Products:

[-20℃to +50℃] 20% to 80%RH

- (Depending on the material being applied, the environmental requirements of the adhesive may vary on different materials).



- Shelf Life: One year when stored unsealed, protected from light, at 23±5°C and 50±10% relative humidity.



- From the date of manufacture, 1 year at 23±5℃ / 50% ±10%RH), un-sealed in the vacuum bag and avoid direct sunlight exposure.

- Declaration: The above environmental requirements are based on our latest knowledge and existing experience, and we reserve the right to interpret the products.



- Disclaimer: Our recommendations are based on our latest knowledge and experience, we reserve all rights for final explanation.
